QX-R Slitter Rewinder

The QX-R slitter rewinder is highly praised for its versatility in its ability to slit spunlaced, needle-punched, melt-blown, heat seal and spun bound non-woven fabrics. In addition, this non-woven slitting and rewinding machine can serve as textile equipment for slitting textile materials, and can also function as a paper slitting machine. Major parts of the slitter rewinder are manufactured by a CNC lathe or machining center, which ensures a higher machining precision and a precise slitting size with no rough edges. The high speed of 100-150m/minute ensures the production efficiency.

Specifications of the Slitter Rewinder
Model: QX-R (1200-3500)
Slitting device: Shear type round knife
Unwinding device: Double roll, magnetic powder tension controller, wide belt
Rewinding device: Pneumatic pressing
Controller: Variable frequency speed control
Drive: Stepping motor
Parameter setting: Human-machine interface
Compressed air: Customer provided
Power supply: 380V, 50Hz, 3-7Kw
Weight: about 3000kg (Specific weight depends on configurations.)

1. This roll slitter can conduct automatic routing, counting, slitting and rewinding simultaneously.
2. It is equipped with an infrared ray automatic counting device, and an auto stop unit.
3. Spiral perforating is quick, smooth and steady. The perforating slant angle can also be adjusted.
4. Due to the gear type with a continuous variable transmission, the distance between perforating lines of the slitter range from 10 cm to 60 cm. With no need to change gears, it can automatically adjust the distance between lines. In addition, it can be equipped with a PLC controller and servo motor to control jointly, making the perforating pitch adjustable.
5. The slitter rewinder uses a variable frequency converter to control the speed, ensuring a convenient operation.
6. It can also come with a magnetic powder tension control system.

This non-woven equipment is suitable for processing cored and coreless, perforated or non-perforated non-woven reels. According to specific customer production requirements, the slitter rewinder delivers various winding and unwinding methods, as well as a magnetic powder tension control, lateral tension control, conveyor belt control, and servo control modes for the best slitting effects. The slitter can be selected individually, and for specifics, please feel free to contact us.
