QX-R1500 Slitter Rewinder

The QX-R1500 slitter rewinder is a versatile non-woven machine for spunlaced, needle punched, melt-blown and spunbound non-woven materials and works well on textiles and paper. The machine speed reaches as high as 60-90 meters/minute. Equipped with 5 groups of folding devices, this slitter rewinding machine can automatically complete the folding and rewinding processes after slitting, all at a great synchronized rate.

The automatic slitter uses CVT, making the distance between the lines adjustable at a range of 10-60cm, and also ensures the slitting face is flat and blur free. Designed with tension control devices, the roll rewinder can rewind cored or coreless rolls and can also rewind non-woven web with or without scoring. It can also be outfitted with adjustable taking up rollers to meet customer production requirements.

Model: QX-R1500
Slitting device: Shear type round knife
Perforating type: Spiral perforating
Rewinding type: Pneumatic
Control mode: Frequency control
Drive: Variable frequency motor
Production speed: 60-90m/min (It depends on material characteristics)
Compressed air: customer provided
Power supply: 380V, 50Hz, 5.5Kw
Weight: about 2300kg (It depends on machine configurations.)

1. This slitter rewinder has an automatic counting and shut down function with the use of an infrared ray.
2. It is equipped with 5 folding units, which ensure an automatic and synchronous folding, scoring, and rewinding process after the slitting.
3. The rewinding roll comes with a continuous variable transmission that can adjust the rewinding speed.
4. The slitter rewinder features a wide belt conveying and pneumatic unwinding, and also uses a continuous tension control device. It conducts real spiral perforating, and it’s fast and stable.
5. This automatic slitting machine is equipped with a high precision aluminum alloy wrinkle removal roller.
6. It can continuously adjust the speed and slitting size.
7. The slitter rewinder can pneumatically adjust the transporting roll, and implement air driven automatic feeding and synchronous conveying.
8. The slitting unit on the non-woven slitter is equipped with a pneumatic device, allowing the slitting knife to move both automatically and horizontally.
9. The non-woven machine is driven by a non-variable frequency motor.
